NovaStar H_4x Fiber Input Card
Carry video into your H-Series processor over long-distance fiber. The H-Series 4x 10G Fiber (OPT) Input Card provides four 10G optical ports (SFP+), each up to 4096x2160@30Hz, with independent and mosaic input modes, automatic source identification, and 144Hz support — using multi-mode (SR) or single-mode (LR) modules for runs up to 10 km. Compatible with the H2, H5, H9, H15 and H20 modular video wall processors.
Retail first-order promo only. Dealer, custom-pricing, and terms accounts cannot combine this with special pricing.
Ideal Applications
Perfect for a wide range of professional LED display scenarios
Long-distance signal transport
Large venues, stadiums & touring
Fiber-based NovaStar front-end systems
Interference-prone or high-EMI environments
Why fiber input for your LED wall?
Copper has limits — once a source is more than a few dozen meters away, HDMI and even SDI become unreliable. Fiber solves that: it carries high-bandwidth video over hundreds of meters (multi-mode) or up to 10 km (single-mode), immune to electrical interference.
With four 10G optical ports, independent and mosaic modes, and automatic source detection, this card is built for big installs where the processor and the sources live far apart — stadiums, touring rigs, and fiber-distributed NovaStar systems.
Key Highlights
Technical Specifications
4x 10G OPT
| Max Resolution | 4096×2160@30Hz per connector |
| Optical Module | Supports SFP+ encapsulation |
Specifications
- 4x 10G OPT ports
- Each connector supports up to 2x SL inputs or 1x DL input
- Supports input mosaic
- Supports two input modes: independent and mosaic modes
- Supports automatic identification of input source resolution and color space
- Supports 144Hz input
- Input resolution settings are not allowed
- In Independent mode, only two OPT ports (either OPT 1~2 or OPT 3~4) can be used for SL input
Frequently Asked Questions
How far can fiber run?
With multi-mode (SR) modules, up to a few hundred meters; with single-mode (LR) modules, up to 10 km — far beyond what HDMI or SDI coax can reach.
What resolution does each port support?
Each of the four 10G OPT ports supports up to 4096x2160@30Hz, and the card supports 144Hz input.
What are independent and mosaic modes?
Independent mode treats each input separately; mosaic mode stitches inputs into a larger canvas. Note that in Independent mode only two OPT ports (OPT 1-2 or OPT 3-4) can be used for SL input.
What optical modules are needed?
SFP+ modules — multi-mode 10G SFP+ SR for shorter runs or single-mode 10G SFP+ LR for long runs.
Does it detect the source automatically?
Yes — it automatically identifies input source resolution and color space. Manual input resolution settings are not allowed.
Which processors is this card compatible with?
It works in the H2, H5, H9, H15 and H20 modular video wall processors, using one input slot.
What warranty is included?
All NovaStar products include a full 3-year manufacturer warranty when purchased from authorized distributors like Olympian LED.
