NovaStar NovaPro UHD
Retail first-order promo only. Dealer, custom-pricing, and terms accounts cannot combine this with special pricing.
Key Highlights
Key Features
Technical Specifications
Video Processing
| Layers | 6 layers |
| Maximum Pixels | 10.4 million pixels |
| Max Input Resolution | 4K×2K@60HZ |
Input Connectors
| SDI | 4x 12G-SDI (IN-LOOP) |
| DP | 1x DP 1.2 |
| HDMI | 1x HDMI 2.0 (IN-LOOP), 4x HDMI 1.3 |
Input Resolution Capabilities
| 12G-SDI | |
| Standard | 12G-SDI up to 4K×2K@60Hz |
| Notes | Supports ST-2082-1 (12G), ST-2081-1 (6G), ST-424 (3G) and ST-292 (HD). Connector 4 supports deinterlacing processing. Supports 12G-SDI output with loop-through. Note: When input is 12G-SDI signal, CANARE / L-4.5CHD+ / UHDTV-SDI SDI cable required (max 50m). |
| DP 1.2 | |
| Standard | DisplayPort 1.2 up to 4K×2K@60Hz (8K×1K@60Hz) |
| Notes | HDCP 1.3 compliant. Does NOT support interlaced input signals. |
| HDMI 2.0 | |
| Standard | HDMI 2.0 up to 4K×2K@60Hz (8K×1K@60Hz) |
| Notes | HDCP 1.4 and HDCP 2.2 compliant. Does NOT support interlaced input signals. Supports HDMI 2.0 output with loop-through. |
| HDMI 1.3 | |
| Standard | HDMI 1.3 up to 1920×1080@60Hz per connector |
| Notes | D_4×HDMI 1.3 input card (can be replaced by a D_4×DVI input card). HDCP 1.3 compliant. Supports interlaced input signals. |
Physical Specifications
| Net weight | 21.0 kg (46.3 lbs) |
Software
| NovaLCT 5.9.2 | |
| Compatible Software | NovaLCT, Web |
Frequently Asked Questions
What size LED wall can the NovaPro UHD drive?
The NovaPro UHD can drive 10.4 million pixels with multiple Ethernet outputs, suitable for medium to large-scale LED displays.
Is the NovaPro UHD suitable for rental applications?
Absolutely. The NovaPro UHD is designed for professional rental, staging, and touring applications where reliability is critical.
What software controls the NovaPro UHD?
The NovaPro UHD is configured and controlled with NovaLCT, Web, a free download from Olympian LED.
What warranty is included?
All NovaStar products include a full 3-year manufacturer warranty when purchased from authorized distributors like Olympian LED.
Do you offer volume pricing?
Yes! As the largest NovaStar distributor in the USA, we offer special pricing for bulk orders and repeat customers. Contact our sales team for a custom quote.
Do you have this in stock?
We keep over $2 million in inventory at our Titusville, Florida warehouse, and most orders ship same-day. Even if a product shows out of stock on the site, email us before you rule it out — we may have just received a batch we have not logged yet, have reserved units that freed up, or have more arriving within a day, and if not we can usually source it fast. We will check the real count and get right back to you.
Can I get NET 30 payment terms?
NET 30 terms are available for qualified businesses and established customers. Please contact our sales team to discuss payment options.
